Skyridge Power
Apex Mobile
Wheeled 16 kWh mobile battery energy storage system. 12 kW continuous output, LiFePO4 chemistry, and solar-ready — built for productions, jobsites, and field operations that need clean power on the move.
- 12 kW continuous
- 16 kWh LiFePO4
- Solar-ready
- Wheeled & mobile
Overview
The Apex Mobile is a self-contained, wheeled BESS designed for deployments where power needs to move with the crew. Built around a 16 kWh LiFePO4 battery and a 12 kW split-phase hybrid inverter, it delivers quiet, emission-free electricity to set operations, base camp, jobsite support zones, and temporary office setups without the noise or logistics of a generator.
What it delivers
- 12 kW continuous / 13.2 kVA peak output — enough for set support, office equipment, tools, and lighting circuits
- 16 kWh LiFePO4 capacity (14.4 kWh usable) with 6,000+ cycle life and no thermal runaway risk
- Wheeled enclosure for on-site repositioning without equipment or lifts
- Solar input up to 18 kW (four independent MPPT channels, 120–500 V range) for daytime recharge
- < 20 ms transfer time — clean transition with no perceptible interruption to loads
- Split-phase 120/240 V AC output with 200 A grid passthrough capability
Specifications
Specifications are based on component datasheets. Contact us for system configuration guidance.
System Output
- Continuous Output Power
- 12,000 W (12 kW)
- Max. Apparent Power (on-grid)
- 13,200 VA
- Backup Output (nominal)
- 12,000 VA
- Max. Backup Output (with PV)
- 13,200 VA
- Output Configuration
- Split-phase 120 / 240 V AC
- Nominal Output Frequency
- 60 Hz
- Transfer Time
- < 20 ms
- Max. Grid Passthrough Current
- 200 A
- Peak Power (off-grid)
- 110% for 30 s / 120% for 10 s / 200% for 5 s
- Output Power Factor
- 0.8 leading – 0.8 lagging
- Output THDu
- < 2%
Battery
- Nominal Capacity
- 16 kWh
- Usable Capacity (90% DoD)
- 14.4 kWh
- Chemistry
- LiFePO4 (Lithium Iron Phosphate)
- Nominal Voltage
- 51.2 V
- Operating Voltage Range
- 43.2 – 58.4 V
- Nominal Charge / Discharge Power
- 10 kW
- Peak Discharge Power
- 11.6 kW (3 seconds)
- Max. Charge Current
- 200 A
- Cycle Life
- 6,000+ cycles
- IP Rating
- IP65
- Communication
- CAN / RS485
- Protection
- Over-current, over-voltage, short circuit, under-voltage
- Certifications
- UN38.3 / UL1973
- Warranty
- 10 years
- Life Span
- > 15 years
- Scalability
- Up to 16 units in parallel (257 kWh total)
Inverter
- Rated Output Power (on-grid)
- 12,000 W (12 kW)
- Max. Apparent Power (on-grid)
- 13,200 VA
- Nominal AC Voltage
- 120 / 240 V (split-phase)
- Nominal AC Current
- 50 A
- Max. AC Current
- 55 A
- No. of MPPT Trackers
- 4
- Max. DC Input Power
- 18 kW
- MPPT Voltage Range
- 120 – 500 V
- Max. DC Input Voltage
- 500 V
- Max. Input Current per MPPT
- 16 A
- Battery Nominal Voltage
- 48 V
- Battery Voltage Range
- 40 – 58 V
- Max. Charge / Discharge Current
- 250 / 260 A
- MPPT Efficiency
- 99.9%
- Max. PV to Grid Efficiency
- 96.5%
- Max. Battery to Load Efficiency
- 94.6%
- IP Rating
- IP65 / NEMA 3R
- Communication
- RS485, CAN, Wi-Fi (4G optional)
- Safety Certifications
- UL1741, UL1741SA&SB, UL1699B, IEEE 1547, IEEE 2030.5, CA Rule 21
- Cooling
- FAN cooling
Enclosure & Mobility
- Mobility
- Wheeled platform — repositionable by one or two crew
- Recharge Sources
- Grid (AC), generator, or solar (up to 18 kW via 4 MPPT channels)
- Intended Use
- Commercial temporary power, production, construction
Typical applications
Apex Mobile is suited to operations where reliable, quiet, and portable power matters.
- Film and television set operations, base camp, and camera village
- Construction site trailers, tool charging, and intermittent site loads
- Ventilation-limited and enclosed work environments
- Temporary events, field operations, and mobile crew support
Get specifications for your project
The Apex Mobile fills the gap between a portable power station and a full site BESS — capable enough to run a production base camp or a jobsite trailer cluster, and mobile enough to move when the work does.
